Airport Information

ARP coordinates and site at AD	343758N / 1351326E 091°/ 1.25km from RWY 09 THR
Direction and distance from (city)	8km (4.3nm) S from Sannomiya Station
Elevation / Reference temperature	22ft / -
Geoid undulation at AD ELEV PSN	121ft
MAG VAR / Annual change	7°W (FEB 2006) / Annual Change 0.8'W
AD Administration , address telephone , telefax	KOBE CITY OFFICE , PUBLIC AP 1 Kobekuko Chuo-ku Kobe city Hyogo pref 650-0048 Japan Tel : +81-78-306-4195 Fax : +81-78-306-4196
Types of traffic permitted (IFR / VFR)	IFR / VFR
Remarks	Kobe Airport Branch (CAB) 1 Kobekuko Chuo-ku Kobe city Hyogo pref 650-0048 Japan Tel : +81-78-304-3993 Fax : +81-78-304-3806

Designations RWY NR	TRUE BRG	Dimensiond of RWY	Strength(PCN) and surface of RWY	THR coordinates THR geoid undulation	THR elevation and highest elevation of TDZ of precision APP RWY
09	084.61°	8200×200 (ft)2500×60 (m)	PCN 63/F/B/X/T Asphalt Concret	343753.91N 1351237.12E 121ft	THR ELEV : 26.7ft TDZ ELEV : 25.2ft
27	264.61°	8200×200 (ft)2500×60 (m)	PCN 63/F/B/X/T Asphalt Concret	343801.53N 1351414.84E 122ft	THR ELEV : 25.9ft TDZ ELEV : 24.2ft
